Engine Specifications

• Model: Perkins 1106D-70TAG3
• Configuration: 6 Cylinder, 4 Stroke
• Displacement: 7.0 L
• Aspiration: Turbocharged
• Cooling System: Water Cooled
• Engine Speed: 1500 rpm

Electrical System

• Voltage: 400/230V
• Frequency: 50 Hz
• Power Factor: 0.8
• Alternator: Brushless, Self-Exciting

Technical Details

• Fuel Type: Diesel
• Fuel Consumption:
• 75% Load: 14.0 L/hr
• 50% Load: 9.8 L/hr
• 25% Load: 6.3 L/hr

Dimensions and Weight

Open Set:

• Length: 2550 mm (100.4 in)
• Width: 1020 mm (40.2 in)
• Height: 1420 mm (55.9 in)
• Dry Weight: 1075 kg (2,370 lbs)

Optional Features

• Soundproof Enclosures
• Advanced Control Panels
• Automatic Transfer Switches
• Extended Fuel Tanks
• Custom Painting
• Remote Monitoring Systems
• Climate-Specific Modifications

Warranty and Compliance

• Warranty: 12 months or 2000 hours (whichever comes first)
• Compliance: ISO 8528, BS5000, IEC 60034

Typical Applications

• Construction Sites
• Industrial Facilities
• Mining Operations
• Agricultural Installations
• Emergency Backup Power
• Rental Power Solutions
• Remote Location Power Generation
• Infrastructure Projects
