FG Wilson P9.5-4 Generator Set
Key Features
Prime and Standby Power Options
Perkins 403D-11G Engine
Available in Multiple Voltage Configurations
50 Hz and 60 Hz Frequency Options
Compact Skid-Mounted Design
Heavy Duty Fabricated Steel Base Frame
Prime and Standby Power Options
Perkins 403D-11G Engine
Available in Multiple Voltage Configurations
50 Hz and 60 Hz Frequency Options
Compact Skid-Mounted Design
Heavy Duty Fabricated Steel Base Frame
More Details
Technical Specifications
- Engine: Perkins 403D-11G
- Cylinders: 3
- Cooling Method: Water
- Fuel Tank Capacity: As per specifications
Dimensions
- Length: 1550 mm (61 in)
- Width: 620 mm (24.4 in)
- Height: 1020 mm (40.2 in)
- Dry Weight: 226 kg (498 lbs)
Optional Features
- CE Certification Upgrade
- Sound Attenuated Enclosures
- Generator Set Control Panels
- Additional Alarms and Shutdowns
- Various Exhaust Silencer Noise Levels
Warranty
- Prime Application: 12 months from start-up, unlimited hours
- Standby Application: 24 months from start-up, limited to 500 hours per year
Compliance
- Meets standards: BS5000, ISO 8528, ISO 3046, IEC 60034, NEMA MG-1.22
