Engine Specifications

• Model: Perkins 1106D-70TAG3
• Configuration: 6 Cylinder, 4 Stroke
• Displacement: 7.0 L
• Aspiration: Turbocharged
• Cooling System: Water Cooled
• Engine Speed: 1500/1800 rpm

Electrical System

• Voltage Options:
• 50 Hz: 400/230V
• 60 Hz: 220/127V
• Power Factor: 0.8
• Alternator: Brushless, Self-Exciting

Technical Details

• Fuel Type: Diesel
• Fuel Consumption (50 Hz):
• 75% Load: 19.0 L/hr
• 50% Load: 13.3 L/hr
• 25% Load: 8.5 L/hr
• Fuel Consumption (60 Hz):
• 75% Load: 20.7 L/hr
• 50% Load: 14.5 L/hr
• 25% Load: 9.3 L/hr

Dimensions and Weight

Open Set:

• Length: 3000 mm (118.1 in)
• Width: 1150 mm (45.3 in)
• Height: 1620 mm (63.8 in)
• Dry Weight: 1500 kg (3,306 lbs)

Optional Features

• Soundproof Enclosures
• Advanced Control Panels
• Automatic Transfer Switches
• Extended Fuel Tanks
• Custom Painting
• Remote Monitoring Systems
• Climate-Specific Modifications

Warranty and Compliance

• Warranty: 12 months or 2000 hours (whichever comes first)
• Compliance: ISO 8528, BS5000, IEC 60034

Typical Applications

• Large Construction Projects
• Industrial Facilities
• Mining Operations
• Emergency Backup Power
• Rental Power Solutions
• Oil and Gas Industries
• Infrastructure Projects
• Remote Location Power Generation
