Engine Specifications

• Model: Perkins 2506C-E15TAG3
• Configuration: 6 Cylinder, 4 Stroke
• Displacement: 15.2 L
• Aspiration: Turbocharged
• Cooling System: Water Cooled
• Engine Speed: 1500/1800 rpm

Electrical System

• Voltage Options:
• 50 Hz: 400/230V
• 60 Hz: 220/127V
• Power Factor: 0.8
• Alternator: Brushless, Self-Exciting

Technical Details

• Fuel Type: Diesel
• Fuel Consumption (50 Hz):
• 75% Load: 74.3 L/hr
• 50% Load: 52.0 L/hr
• 25% Load: 33.4 L/hr
• Fuel Consumption (60 Hz):
• 75% Load: 81.0 L/hr
• 50% Load: 56.7 L/hr
• 25% Load: 36.4 L/hr

Dimensions and Weight

Open Set:

• Length: 5000 mm (196.9 in)
• Width: 1900 mm (74.8 in)
• Height: 2400 mm (94.5 in)
• Dry Weight: 4800 kg (10,582 lbs)

Optional Features

• Soundproof Enclosures
• Advanced Control Panels
• Automatic Transfer Switches
• Extended Fuel Tanks
• Custom Painting
• Remote Monitoring Systems
• Climate-Specific Modifications

Warranty and Compliance

• Warranty: 12 months or 2000 hours (whichever comes first)
• Compliance: ISO 8528, BS5000, IEC 60034

Typical Applications

• Global Market Versatility
• Large Industrial Facilities
• Major Construction Projects
• Mining Operations
• Infrastructure Development
• Emergency Backup Power
• Rental Power Solutions
• Oil and Gas Industries
• Large Commercial Complexes
• Marine Applications
• Remote Location Power Generation
