Engine Specifications

• Model: Perkins 1104D-44TAG2
• Configuration: 4 Cylinder, 4 Stroke
• Displacement: 4.4 L
• Aspiration: Turbocharged
• Cooling System: Water Cooled
• Engine Speed: 1800 rpm

Electrical System

• Voltage: 220/127V
• Frequency: 60 Hz
• Power Factor: 0.8
• Alternator: Brushless, Self-Exciting

Technical Details

• Fuel Type: Diesel
• Fuel Consumption:
• 75% Load: 6.8 L/hr
• 50% Load: 4.8 L/hr
• 25% Load: 3.1 L/hr

Dimensions and Weight

Open Set:

• Length: 2030 mm (80 in)
• Width: 868 mm (34.2 in)
• Height: 1230 mm (48.4 in)
• Dry Weight: 675 kg (1,488 lbs)

Optional Features

• Soundproof Enclosures
• Advanced Control Panels
• Automatic Transfer Switches
• Extended Fuel Tanks
• Custom Painting
• Remote Monitoring Systems

Warranty and Compliance

• Warranty: 12 months or 2000 hours (whichever comes first)
• Compliance: ISO 8528, BS5000, IEC 60034

Typical Applications

• Construction Sites
• Industrial Facilities
• Commercial Buildings
• Rental Power Solutions
• Emergency Backup Power
• North American Market Applications
