Technical Specifications

• Engine: Perkins 404D-22G
• Cylinders: 4
• Cooling Method: Water
• Fuel Type: Diesel
• Engine Speed: 1500/1800 rpm
• Aspiration: Naturally Aspirated

Dimensions

• Length: 1700 mm (66.9 in)
• Width: 720 mm (28.3 in)
• Height: 1180 mm (46.5 in)
• Dry Weight: 450 kg (992 lbs)

Optional Features

• CE Certification Upgrade
• Sound Attenuated Enclosures
• Generator Set Control Panels
• Synchronising Capabilities
• Additional Alarms and Shutdowns
• Various Exhaust Silencer Options

Warranty

• Prime Application: 12 months from start-up, unlimited hours
• Standby Application: 24 months from start-up, limited to 500 hours per year

Compliance and Standards

• Meets international standards: BS5000, ISO 8528, ISO 3046, IEC 60034, NEMA MG-1.22

Environmental Conditions

• Designed to operate in ambient temperatures up to 50°C (122°F)
• Maximum Altitude: Up to 1000m above sea level

Typical Applications

• Construction Sites
• Industrial Facilities
• Emergency Backup Power
• Rental and Hire Operations
• Remote Locations
• Event Power Solutions
