Engine Specifications

• Model: Perkins 1506C-E88TAG4
• Configuration: 6 Cylinder, 4 Stroke
• Displacement: 8.8 L
• Aspiration: Turbocharged
• Cooling System: Water Cooled
• Engine Speed: 1500 rpm

Electrical System

• Voltage: 400/230V
• Frequency: 50 Hz
• Power Factor: 0.8
• Alternator: Brushless, Self-Exciting

Technical Details

• Fuel Type: Diesel
• Fuel Consumption:
• 75% Load: 36.5 L/hr
• 50% Load: 25.6 L/hr
• 25% Load: 16.4 L/hr

Dimensions and Weight

Open Set:

• Length: 3900 mm (153.5 in)
• Width: 1350 mm (53.1 in)
• Height: 1950 mm (76.8 in)
• Dry Weight: 2450 kg (5,401 lbs)

Optional Features

• Soundproof Enclosures
• Advanced Control Panels
• Automatic Transfer Switches
• Extended Fuel Tanks
• Custom Painting
• Remote Monitoring Systems
• Climate-Specific Modifications

Warranty and Compliance

• Warranty: 12 months or 2000 hours (whichever comes first)
• Compliance: ISO 8528, BS5000, IEC 60034

Typical Applications

• Large Industrial Facilities
• Major Construction Projects
• Mining Operations
• Infrastructure Development
• Emergency Backup Power
• Rental Power Solutions
• Oil and Gas Industries
• Large Commercial Complexes
• Agricultural Installations
• Remote Location Power Generation
